AKTIPRINT MINI LED - UV LED DRYER

Describe

LECI is the Authorized distributor of AKTIPRINT MINI LED - TECHNIGRAF UV LED DRYER in Vietnam

AKTIPRINT MINI LED - UV LED DRYER

Compact UV table top dryer with Light Emitting Diodes (LED) 395 nm. For curing and hardening of UV sensitive LED inks and varnishes as well as adhesives. Ideal for tests, R & D or occasional small production runs on flat material and moulded parts of small size.

  • Manufacturer: TECHNIGRAF (Germany)
  • Application: drying
UV LED wave length395 nm (other wave lengths on request)
UV LED powermax. 16 W/cm², infinitely variable
UV LED curing width8 or 12 cm respectively 16 cm
Standard versionReady to use UV LED table unit, ozone free.
Teflon coated, endless, glass fibre conveyor belt.
Belt suction to prevent material from floating.
FeaturesUV LED requires no run-up phase and no cool-down phase.
Instant curing. No waiting times.
Monochromatic UV spectrum 395 nm.
High efficient light system. No creation of ozone. No exhaust needed.
Highly stabilized, infinitely variable UV LED power.
Low heat load at the material.
Conveyor belt speed3-20 m/min., variable
Conveyor beltTeflon coated, endless, glass fibre conveyor belt, black, antistatic
Conveyor belt width11 respectively 17 cm
Max. pass through widthapprox. 22 cm
Max. curing width8 or 12 cm respectively 16 cm
Tunnel height12 – 50 mm, easily manual adjustable
ColourRAL 9005, black and RAL 7035, grey
Manual instructionGerman or English

Article No.Description
UN50201AKTIPRINT Mini LED 8 cm - 16 W/cm² - 395 nm / 230 V, 50 Hz – belt 75 cm
UN50202AKTIPRINT Mini LED 12 cm - 16 W/cm² - 395 nm / 230 V, 50 Hz – belt75 cm
UN50203AKTIPRINT Mini LED 16 cm - 16 W/cm² - 395 nm / 230 V, 50 Hz – belt 75 cm
Accessories
UN50000-14Inclined material deposit, adjustable in steps
UN50000-30Digital conveyor belt speed indicator
7095019Colour if different from RAL 9005 and RAL 7035
UN50000-98
UN50000-99
