Electron Tubes 3CX2500H3

We are a leading electron tube supplier in Asia, offering the Electron Tubes CX2500H3 with ready stock.

Specifications Electron Tubes 3CX2500H3

• Maximum Plate Dissipation: 4,000 Watts

• Maximum Screen Dissipation: 150 Watts

• Maximum Grid Dissipation: 150 Watts

• Frequency for Max Rating (CW): 75 MHz

• Amplification Factor: 20

• Filament/Cathode: Thoriated Tungsten

• Filament Voltage: 7.5 Volts

• Filament Current: 51.5 Amps

• Cooling: Forced Air

• Base: Flexible Filament Leads

• Length: 18.44 in; 468.40 mm

• Diameter: 4.16 in; 105.70 mm

• Weight: 7.5 lb; 3.4 kg

Our experienced technical team provides installation and repair services to ensure optimal performance. We also offer fast international shipping to meet the needs of customers worldwide.
