Electron tubes 3CX6000A7 / YU-148

Specifications:

• Plate Dissipation (Max.): 6,000 Watts

• Grid Dissipation (Max.): 225 Watts

• Frequency for Max. rating (CW): 110 MHz

• Amplification Factor: 200

• Filament/Cathode: Thoriated Tungsten

• Voltage: 7.0 Volts

• Current: 78.0 Amps

• Capacitance (Input): 42.0 pf

• Capacitance (Output): 0.28 pf

• Capacitance (Feedthrough): 24.0 pf

• Base: Coaxial

• Length: 9.0 in; 22.86 cm

• Diameter: 6.125 in; 15.56 cm

• Weight: 9.1 lb; 4.1 kg
