JAN - 8613 Electron Tubes Specifications:
Max Peak Anode Voltage (epy): 16 kV
Max Peak Anode Current (ib): 500 A
Max Average Anode Current (Ib): 0.5 A DC
RMS Anode Current (Ip): 8 A RMS (computed as the square root of the product of peak current and average current)
Maximum Pb (epy x ib x pps): 10 x 10⁹ VApps
Max Anode Current Rate of Rise (dik/dt): 2,000 A/μs
Anode Delay Time (tad): 0.5 μs (measured at epy = 10 kV, ib = 100 A)
Anode Delay Time Drift (∆tad): 0.1 μs
Max Time Jitter (tj): 0.005 μs
Ambient Temperature: -55° to +125° C
Ancillary Supplies:
Peak Grid Voltage (egy): -175 to 600 V
Grid Voltage Pulse Width (tp): 2 μs
Grid Voltage Rise Time (tr): 0.35 μs
Grid Drive Source Impedance (Zg): 250 to 500 Ω
Negative Grid Bias (Ecc): -200 V DC
Heater Voltage (Ef): 6.3 VAC/VDC (5.8 to 6.8 VAC/VDC)
Heater Current at 6.3 V (If): 6 to 11.5 A AC/DC
Warm-up Time (tk): 3 minutes
