YU191B Triode

The YU191B is a high-power triode with a 7.5V thoriated tungsten filament, 5000V plate voltage, and water cooling. It features a 160 amplification factor, special coaxial base, and weighs 5.5 lbs, ideal for high-voltage applications.

YU191B Triode Tube Specifications

• Filament: Thoriated Tungsten, 7.5V ± 0.37V, 51.5A

• Amplification Factor: 160

• Maximum Ratings:

• DC Plate Voltage: 5000V

• DC Plate Current: 2.5A

• Grid Dissipation: 225W

• Cooling: Water (see datasheet for flow requirements)

• Base: Special Coaxial

• Dimensions: 9.8" (L) x 7.1" (W)

• Weight: 5.5 lbs

ELECTRON TUBES, TOSHIBA Canon Electron tubes, Thales Electron Tubes
