LECI is the Authorized distributor of AKTIPRINT MINI E - TECHNIGRAF UV Dryer in Vietnam
The extended version of the AKTIPRINT Mini/e table top dryer has more reserve capacity than the original AKTIPRINT Mini and can be used for continuous operation for a broad range of small format applications. Modern power electronics stabilize the continuously adjustable lamp output (up to 120 W/cm) against fluctuating line voltage and when using lamp types of differing spectral emission. This ensures consistent drying results.
Manufacturer: TECHNIGRAF (Germany)
Application: drying
Power of UV tubemax. 120 W/cm
UV spectrum200 – 400 nm (ozone free tube and special spectra on request)
Standard versionReady to use, compact table unit with 1 UV tube, Hg.
Inclusive quartz glass pane.
Half focussing aluminium reflector.
Direct cooling of the reflector.
Material suction fan / belt suction.
Teflon coated, endless, glass fibre conveyor belt.
FeaturesOzone exhaust not necessary.
High, stabilized and variable power of the UV tube up to 120 W/cm.
Improved cooling of material.
Useful for longer production operations.
Conveyor belt speed3-20 m/min., variable
Conveyor beltTeflon coated, endless, glass fibre conveyor belt, black, antistatic
Conveyor belt widthMini/e 12: 11 cm, Mini/e 18: 17 cm
Max. pass through widthapprox. 22 cm
Max. curing widthMini/e 12: 6 cm, Mini/e 18: 10 cm
Tunnel height12 – 50 mm, easily manual adjustable
ColourRAL 5002, blue and RAL 7035, grey
Manual instructionGerman or English
NoteWhen increased tunnel height is used, ensure that max. light emission limit is not
UN50053AKTIPRINT Mini/e 12-1 / 230 V, 50 Hz – belt 75 cm
UN50059AKTIPRINT Mini/e 18-1 / 230 V, 50 Hz – belt 75 cm
UN50000-14Inclined material deposit, adjustable in steps
UN50000-30Digital conveyor belt speed indicator
7095019Colour if different from RAL 5002 and RAL 7035
UN50000-98Packing overland freight (cardboard box on pallet)
UN50000-99Packing sea freight (sea crate)
